Chemical formula NbB2: Niobium-boride. This chemical has the following characteristics: high melting point; high hardness; good thermal and electrical conductivity; resistance to metal erosion; superconductivity.
Purity: 99%
Particle sizes: 5-10um
Niobium Boride, NbB2 Powder
Niobium boridide NbB2 can have a high melting and hardness. This makes it ideal for superconducting materials. Niobium biboride can be described as a covalent refractory ceramic material of high quality with a hexagonal crystal.
15giorni TM is a respected global Niobium Boride supplier. Please feel free to inquire about the Niobium Boride cost.
Product Performance of Niobium Boride NbB2 Powder:
The chemical formula for Niobium Boride (NbB2) has a molecularweight 114.528. It is gray-black in color.
Parameter Technical of Niobium Boride Powder NbB2:
– Particle Size
Niobiumboride NbB2 Puffer:
How Niobium Boride NiB2 Powder Is it Produced?
NbB2 could be created by the stoichiometric reacting of components elements. This reaction allows for precise stoichiometric controls of materials. Also, metallothermic reduce can also be done to reduce Nb2O5 (or NbO2) into niobium disboride. The reaction is described in the next section.
Nb2O5 + 2 B2O3 + 11 Mg → 2 NbB2 + 11 MgO
The reactant is Mg to permit acid leaching. Stoichiometric excesses Mg/B2O3 may be required to consummate all of the available Niobium oxide.
Jha and coworkers suggested borothermal reduction of NbO2 via solid state reaction to produce nanorods (20 800 nm2)
Ran and coworkers have proposed a modified borothermal reduction of molten salt. Ran, along with his colleagues, used Nb2O5 in combination with elemental boron (61 nm)
Zoli’s method of synthesizing NbB2 nanocrystals was successful. It involved a reduction in Nb2O5 using NaBH4 for 30 min at 700 °C under argon flow.
Nb2O5 + 13/2 NaBH4 → 2 NbB2 + 4Na(g,l) + 5/2 NaBO2 + 13 H2(g)
Niobium Boride NibB2 Pulver
NbB2, an ultrahigh-temperature ceramic (UHTC), is a high-temperature material. With a melting-point of 3050° C, it has good thermal conductivity and electrical resistance. The ceramic’s thermal conductivity is very high and its electrical conductivity is excellent (resistivity 25.7 Ybcm; Cte 7.7Yb106°C1). It shares many of the same properties with titanium diboride.
It is common to heat press or spark plasma-sinter NbB2 pieces (mechanical pressure is applied on the heated powder). The part then gets machined. NbB2 has a high covalentity and is therefore difficult to melt. This sintering agent reacts with surface oxides and increases the sintering strength. However, NbB2’s mechanical properties will decrease in hot pressing sintering.
Packing & Shipping Niobiumboride NbB2 Poultry:
There are many packing options available that depend on how much Niobium Boride NbB2 powder you have.
Niobium Boride NbB2 granule packing: vacuum packed, 100g and 500g respectively, 25kg/barrel/or as per your request.
Shipping Niobium Boride NbB2 dust: Can be shipped either by sea or by air after receipt of payment.
Luoyang Tongrun 15giorni Technology Co. Ltd.
Contact us if you need niobium-boride powder of high quality. (brad@ihpa.net)
Niobium Boride Properties
Niobium Boride Health & Safety
